Please email me to order
Nominal thrust: 210N(47.2lbs) at 122.000 RPM
Idle thrust: 6N Idle RPM: 28,000
Diameter: 110,9mm (4.36”)
Engine weight: 1.620g (3.3lb)
Installed weight: 1,650g (3,65lb)
Fuel: Kerosene/Diesel + 3% – 5% oil
Fuel consumption: 560g/minStart mode: Direct Kerosene
After 10 years of production of the M160, it was time for a full upgrade. The new engine has received a state of the art, all new electronics package, the M200 has received the new XBUS system, integrated valves, brushless starter motor and brushless pump. Sensors and valves are installed inside the engine, further simplifying installation.
The engine has a single fuel input directly from the pump, and a 3-wire electrical connection to the ecu that carries the battery power and a bidirectional digital bus. All engine data is transmitted to the ecu in a digital data format, using a high speed proprietary protocol specially developed for this application. The bus design allows a distance up to 15meters from engine to ecu while keeping the generated noise by the bus to a very low level to not affect other devices nor to be affected by them. All engine parameters and timers are stored within the engine, installation parameters (radio settings, etc) are stored in the External ecu, enabling the swap of the engine without any adjustment. One engine can now be relocated in multiple airframes, additional Pump and External ECU are the only additions needed. Includes engine and all ancillary accessories needed to run the engine, except the battery. Recommended LiPo 11,1v 2200mAh
Be advised shipping via the checkout only includes carrier basic insurance with quotes, if you require full insurance please contact me.
